WPF C# .NET Framework4.7.2

WPF 연습(경비보고서)

[ExpenseItHome.xaml]

<Page x:Class="ExpenseIt.ExpenseItHome"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:local="clr-namespace:ExpenseIt"
      mc:Ignorable="d"
      d:DesignHeight="350" d:DesignWidth="500"
      Title="ExpenseIt - Home">

    <Grid Margin="10,0,10,10">
        <Grid.Background>
            <ImageBrush ImageSource="watermark.png"  />
        </Grid.Background>

        <Grid.ColumnDefinitions>
            <ColumnDefinition Width="230" />
            <ColumnDefinition />
        </Grid.ColumnDefinitions>

        <Grid.RowDefinitions>
            <RowDefinition/>
            <RowDefinition Height="Auto"/>
            <RowDefinition />
            <RowDefinition Height="Auto"/>
        </Grid.RowDefinitions>

        <Grid.Resources>
            <!-- Expense Report Data -->
            <XmlDataProvider x:Key="ExpenseDataSource" XPath="Expenses">
                <x:XData>
                    <Expenses xmlns="">
                        <Person Name="준영" Department="Bigdata">
                            <Expense ExpenseType="분석" ExpenseAmount="50" />
                            <Expense ExpenseType="시각화" ExpenseAmount="50" />
                        </Person>
                        <Person Name="민욱" Department="Backend-Dev">
                            <Expense ExpenseType="Document printing"
          ExpenseAmount="50"/>
                            <Expense ExpenseType="Gift" ExpenseAmount="125" />
                        </Person>
                        <Person Name="수진" Department="Bigdata">
                            <Expense ExpenseType="분석"
         ExpenseAmount="50"/>
                            <Expense ExpenseType="New machine" ExpenseAmount="600" />
                            <Expense ExpenseType="Software" ExpenseAmount="500" />
                        </Person>
                        <Person Name="예은" Department="Bigdata">
                            <Expense ExpenseType="분석" ExpenseAmount="100" />
                        </Person>
                    </Expenses>
                </x:XData>
            </XmlDataProvider>
            <!-- Name item template -->
            <DataTemplate x:Key="nameItemTemplate">
                <Label Content="{Binding XPath=@Name}"/>
            </DataTemplate>
        </Grid.Resources>


        <!-- People list -->

        <Label Grid.Column="1" Style="{StaticResource headerTextStyle}" >
            경비 보고서 열람
        </Label>

        <Border Grid.Column="1" Grid.Row="1" Style="{StaticResource listHeaderStyle}">
            <Label Style="{StaticResource listHeaderTextStyle}">Names</Label>
        </Border>
        <ListBox Name="peopleListBox" Grid.Column="1" Grid.Row="2"
         ItemsSource="{Binding Source={StaticResource ExpenseDataSource}, XPath=Person}"
         ItemTemplate="{StaticResource nameItemTemplate}">
        </ListBox>

        <!-- View report button -->
        <Button Grid.Column="1" Grid.Row="3" Click="Button_Click" Style="{StaticResource buttonStyle}">View</Button>
    </Grid>
</Page>



[ExpenseReportPage.xaml]

<Page x:Class="ExpenseIt.ExpenseReportPage"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:local="clr-namespace:ExpenseIt"
      mc:Ignorable="d"
      d:DesignHeight="350" d:DesignWidth="500"
      Title="Expense - View Expense">

    <Grid>
        <Grid.Background>
            <ImageBrush ImageSource="watermark.png" />
        </Grid.Background>
        <Grid.ColumnDefinitions>
            <ColumnDefinition Width="230" />
            <ColumnDefinition />
        </Grid.ColumnDefinitions>
        <Grid.RowDefinitions>
            <RowDefinition Height="Auto" />
            <RowDefinition />
        </Grid.RowDefinitions>


        <Label Grid.Column="1" Style="{StaticResource headerTextStyle}">
            경비 보고서:
        </Label>
        <Grid Margin="10" Grid.Column="1" Grid.Row="1">

            <Grid.ColumnDefinitions>
                <ColumnDefinition />
                <ColumnDefinition />
            </Grid.ColumnDefinitions>
            <Grid.RowDefinitions>
                <RowDefinition Height="Auto" />
                <RowDefinition Height="Auto" />
                <RowDefinition />
            </Grid.RowDefinitions>

            <!--Templates to display expense report data-->
            <Grid.Resources>
                <!-- Reason item template -->
                <DataTemplate x:Key="typeItemTemplate">
                    <Label Content="{Binding XPath=@ExpenseType}"/>
                </DataTemplate>
                <!-- Amount item template -->
                <DataTemplate x:Key="amountItemTemplate">
                    <Label Content="{Binding XPath=@ExpenseAmount}"/>
                </DataTemplate>
            </Grid.Resources>

            <!-- Name -->
            <StackPanel Grid.Column="0" Grid.ColumnSpan="2" Grid.Row="0" Orientation="Horizontal">
                <Label Style="{StaticResource labelStyle}">Name:</Label>
                <Label Style="{StaticResource labelStyle}" Content="{Binding XPath=@Name}"></Label>
            </StackPanel>

            <!-- Department -->
            <StackPanel Grid.Column="0" Grid.ColumnSpan="2" Grid.Row="1" Orientation="Horizontal">
                <Label Style="{StaticResource labelStyle}">Department:</Label>
                <Label Style="{StaticResource labelStyle}" Content="{Binding XPath=@Department}"></Label>
            </StackPanel>

            <Grid Grid.Column="0" Grid.ColumnSpan="2" Grid.Row="2" VerticalAlignment="Top"
            HorizontalAlignment="Left">
                <!-- Expense type and Amount table -->
                <DataGrid ItemsSource="{Binding XPath=Expense}" ColumnHeaderStyle="{StaticResource columnHeaderStyle}"
                    AutoGenerateColumns="False" RowHeaderWidth="0" >
                    <DataGrid.Columns>
                        <DataGridTemplateColumn Header="ExpenseType" CellTemplate="{StaticResource typeItemTemplate}"/>
                        <DataGridTemplateColumn Header="Amount" CellTemplate="{StaticResource amountItemTemplate}" />
                    </DataGrid.Columns>
                </DataGrid>
            </Grid>
        </Grid>
    </Grid>
</Page>



[App.xaml]

<Application x:Class="ExpenseIt.App"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:local="clr-namespace:ExpenseIt"
             StartupUri="MainWindow.xaml">
    <Application.Resources>
        <!-- Header text style -->
        <Style x:Key="headerTextStyle">
            <Setter Property="Label.VerticalAlignment" Value="Center"></Setter>
            <Setter Property="Label.FontFamily" Value="Trebuchet MS"></Setter>
            <Setter Property="Label.FontWeight" Value="Bold"></Setter>
            <Setter Property="Label.FontSize" Value="18"></Setter>
            <Setter Property="Label.Foreground" Value="#0066cc"></Setter>
        </Style>

        <!-- Label style -->
        <Style x:Key="labelStyle" TargetType="{x:Type Label}">
            <Setter Property="VerticalAlignment" Value="Top" />
            <Setter Property="HorizontalAlignment" Value="Left" />
            <Setter Property="FontWeight" Value="Bold" />
            <Setter Property="Margin" Value="0,0,0,5" />
        </Style>

        <!-- DataGrid header style -->
        <Style x:Key="columnHeaderStyle" TargetType="{x:Type DataGridColumnHeader}">
            <Setter Property="Height" Value="35" />
            <Setter Property="Padding" Value="5" />
            <Setter Property="Background" Value="#4E87D4" />
            <Setter Property="Foreground" Value="White" />
        </Style>

        <!-- List header style -->
        <Style x:Key="listHeaderStyle" TargetType="{x:Type Border}">
            <Setter Property="Height" Value="35" />
            <Setter Property="Padding" Value="5" />
            <Setter Property="Background" Value="#4E87D4" />
        </Style>

        <!-- List header text style -->
        <Style x:Key="listHeaderTextStyle" TargetType="{x:Type Label}">
            <Setter Property="Foreground" Value="White" />
            <Setter Property="VerticalAlignment" Value="Center" />
            <Setter Property="HorizontalAlignment" Value="Left" />
        </Style>

        <!-- Button style -->
        <Style x:Key="buttonStyle" TargetType="{x:Type Button}">
            <Setter Property="Width" Value="125" />
            <Setter Property="Height" Value="25" />
            <Setter Property="Margin" Value="0,10,0,0" />
            <Setter Property="HorizontalAlignment" Value="Right" />
        </Style>
    </Application.Resources>
</Application>



[ExpenseItHome.xaml.cs]

using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace ExpenseIt
{
    /// <summary>
    /// ExpenseItHome.xaml에 대한 상호 작용 논리
    /// </summary>
    public partial class ExpenseItHome : Page
    {
        public ExpenseItHome()
        {
            InitializeComponent();
        }

        private void Button_Click(object sender, RoutedEventArgs e)
        {
            // View Expense Report
            ExpenseReportPage expenseReportPage = new ExpenseReportPage(this.peopleListBox.SelectedItem);
            this.NavigationService.Navigate(expenseReportPage);
        }
    }
}



[ExpenseReportPage.xaml.cs]

using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace ExpenseIt
{
    /// <summary>
    /// ExpenseReportPage.xaml에 대한 상호 작용 논리
    /// </summary>
    public partial class ExpenseReportPage : Page
    {
        public ExpenseReportPage()
        {
            InitializeComponent();
        }
        // Custom constructor to pass expense report data
        public ExpenseReportPage(object data) : this()
        {
            // Bind to expense report data.
            this.DataContext = data;
        }
    }
}
